Designing made easy!

With our directly integrable standards libraries.

Your advantages at a glance:

  • Immediate use of standard parts in your design
  • Time-saving and flexible tool design
  • Quick implementation of activities in the areas of mould design and standard part installation, as there is no need to import external design data
  • Standard parts can be changed or replaced at any time without additional effort
  • Data can be forwarded directly to production
  • Automatic creation of parts lists with all the necessary information

Flyer CAD standard parts libraries [PDF]


VISI

VISI is a leading design and NC programming system for tool and mould making, known for its intuitive design and intelligent standard parts libraries. The advantages include various standardised parts, automatically generated trigger bodies and a parametric mode of operation for fast and flexible design. VISI also offers various CAD interfaces and processing strategies.

MECADAT AG is the official distributor of VISI for Germany, Austria and Switzerland with over 30 years of experience in the CAD/CAM sector for tool and mould making


Creo Parametric

Creo Parametric is a parametric 3D CAD software that delivers precise models quickly and combines parametric and direct modelling. STRACK NORMA has been using Creo for a long time to provide customers and designers with easy access to STRACK standard parts. The benefits include integration of all STRACK demoulding elements, direct modelling, extensions for 3D CAD CAE solutions, integrated NC functions and design for additive manufacturing. A comprehensive range of CAD data for demoulding elements in Creo is now available.

You can download the update 17.0.4.0  here.

Siemens NX

The NX software is a comprehensive CAD solution that helps customers to design complex products efficiently. The benefits include the direct integration of the STRACK database, the assignment of tolerances using colour schemes for efficient dimensioning, automatic parametric design of standard parts in the design and adaptable components.

A comprehensive range of CAD data for demoulding elements in NX format is now available. Further information on the STRACK standard parts library and the CAD standard part app can be found at CIMTEC.


Together with our co-operation partner MW Loge, we are continuously developing our standard parts library.

Flyer CAD standard part app
